Little's Law, M/M/1 and M/M/c queues

How can we predict performance when load testing a server or set of servers? For example, how can we predict max TPS?

magic numbers

If you want, you can take my word for it that you want to use at least 8 physical cores, run at about 70% utilization (if you can’t do both of those things you really don’t need to spend much time thinking about this anyway), run a few requests to measure the latency in milliseconds, and then use this formula to get your max TPS:

where \(c\) = number of cores (or cores * hosts if you have multiple hosts), \(\rho_{\text{target}}\) = target utilization (70%), and \(W\) = base latency.

why though?

Well, it’s a queue, so we’re going to step by step using queuing theory…

Load testing is pretty simple. You send work at a rate (something per something) \(\lambda\), it takes \(W\) on average seconds to do the work, and at any given second you have \(L\) work items getting worked on. That’s Little’s Law: \(L = W \cdot \lambda\), where \(L\) is requests in the system, \(W\) is average base latency in seconds, and \(\lambda\) is the arrival rate of requests/transactions per second.

When doing a load test, you can just run your TPS generator until by some measure you consider the system overloaded: “there’s the max!” But you can also make predictions of what this max, in some sense, should be. You can run a request per second (assuming it runs in under a second) to get the average base latency of your system, \(W\), and if you think about it, you may say that it must equal \(\frac{1}{\mu}\), where \(\mu\) is the maximum TPS the system can take, right?

First observe that it’s a big assumption to believe your system behaves the same idle as it does busy. As your system receives more load, \(\lambda\), you need to absorb that the utilization you read is an average over a second and from the perspective of a given request, it is not guaranteed access to idle resources at any given instant inside that second (measurement window). That is, even well below average 100% utilization, your request can queue. You need a term to model that, which you don’t immediately have in Little’s Law.

To model this factor of utilization, which will cause a waiting time (\(W_q\) or \(P_{\text{wait}}\)), we can use the M/M/1 queue, which tells us that \(W\) under load will become \(\frac{1}{\mu-\lambda}\) (the reciprocal of your spare capacity). That really makes a lot of sense: if other requests are coming to the server in the same second, there’s a chance you will compete. Your average latency is the outcome of a weighted probability, where 30% of the time you arrived and there was no queue, and 70% of the time you arrived there was a queue.

So let’s run an example and say that idle state average latency \(W\) is 0.05s (50 milliseconds). From that you predict your system’s \(\mu\) (max TPS) is 20. (Of course that seems insanely low but don’t worry we’ll get to that in a moment.) This means at 14 TPS (70% utilization), your \(W\) becomes \(\frac{1}{6}\) or 0.167s (167 milliseconds). That is 3.3 times slower than your idle latency.

From this we can also calculate how long requests wait on average when they can hit a queue of potentially multiple requests ahead of them. We know that the total is 0.167s, and the base latency is 0.05s, and so it must be total - base = 0.117s.

There’s actually a dimensionless multiplier you can use directly to calculate “how many times base latency will \(W\) be under arrival load \(\lambda\)?” \(\frac{1}{1-\frac{\lambda}{\mu}}\), where \(\frac{\lambda}{\mu}\) is directly the utilization term, \(\rho\).

Now, you should be asking somewhere in reading the foregoing, “hey, wait a second, what kind of system are we modeling, is it true to my system?”

M/M/1 is a really nice, tractable, understandable model. So obviously it’s also wrong. :) How wrong? We’ll show a table, but let’s actually talk about what it represents first so we have an intuition for why it’s wrong and how to get an exact, correct prediction.

M/M/1 stands for M=Markovian, M=memoryless, 1=worker. Really this models the simplest case: you have one worker handling things serially from one queue. That’s why you can just think of \(\frac{1}{\mu}\) as average latency – imagine a worker standing over a conveyer belt. The \(\frac{1}{1-\frac{\lambda}{\mu}}\) term is just saying, “how long will the average task take when the conveyer belt is adding tasks \(\lambda\)?”

But hey, it’s 2025, and your server has multiple CPUs, and each CPU is probably capable of doing some work for you in parallel. Many server files I see basically do # cpus - 1 to give a server thread sitting on the port and then the rest of the cores are workers handling requests… A scenario properly modeled by M/M/c, where c is the number of cores or servers.

M/M/c uses the Erlang C formula to get the \(W_q\) which is conceptually not too crazy (“what’s the probability all servers are busy over the probability of all server states?”) but it’s a lot of terms to work with in practice.

Zoomed out, we’re still dealing with:

But if we zoom in to \(W_q\), we see:

The blue term is just “what’s the probability that all cores/servers/workers are busy?” And the purple term is just “what’s the probability overall of all other states where only k servers are busy?” As a ratio, you’re asking “what’s the probability all workers are busy out of all their potential busyness states?” That’s the probability you’ll wait.

While \((3)\) isn’t really that bad, it’s a bit much for quick napkin math. We can use an approximation of the queue time for G/G/c by Allen-Cunneen where the exponent is \(\alpha(c) = \sqrt{2(c+1)-1}\). What’s nice about this term is that you can pretty much just memorize common values of \(c\), eg. 16 gives you \(\sqrt{34}-1 \approx 6\). And then \(W_q\) is just \(\frac{\rho^{\alpha(c)}}{c(1-\rho)} \cdot\frac{1}{\mu}\) (service time or \(S\)). This works about like the first pass we did above, where you know your idle time \(W\) is 0.05, and you can multiply it by \(\frac{1}{1-\frac{\lambda}{\mu}}\) with straightforward modifiers from \(c\), \(\rho\), and the approximated power factor. (Recall \(\rho\) is equal to \(\frac{\lambda}{\mu}\).)

Tabling this out, we can see assuming no parallelism massively underestimates our system¹ but that our approximation of Erlang C is pretty decent!

table 1: estimates of latency overhead by utilization, with error

If we do our example with 50ms average base latency, you can see we need to go above 70% before (to my taste anyway) we see significant latency increase:

table 2: estimates of latency by utilization

So if you want a very simple prediction table, you can take common values for cores, which are just bases of two, peg the desired utilization at 70% (you don’t want to waste hardware), and voila you can see your expected latency as a function of \(c\):

table 3: given 70% utilization, what is latency per core count?

You can see that you need to run with some “real” slack in your system to keep overhead low, ie. you want to run at least 8-16 cores to stay close to your base latency. But if you need to spend less money, you can just accept higher latency. That’s often a great option because humans don’t tend to notice 50ms versus 100ms for something like a web server, and (eg.) a 4xl instance (16 vCPUs²) costs 8 times what an l (2 vCPUs) instance costs.

There’s one final observation we can make that handily bookends things. If we peg utilization to 70%, and can assume we have 8+ cores so overhead is negligible, then we can get max TPS just by doing \(\frac{c\rho}{S}\), where \(S\) was just the idle latency we measured by sending a few requests. If you have more hosts, trust your load balancer and just use it to multiply your cores further. This makes your max TPS³ math simple enough to do in your head!
